- “Self-Powered”, No External Power Required
- Easy to Install – Only Two Connections
- Voltages: 50-500V AC
- Resolution to 1V; Accuracies to +/-1%,+/-2LSB
- Reliable, long life, Mcu measuring
- Replacements for 2-Wire Analog Meters
- Sample Speed: about 10 times/sec.
- LED Size/ Color: 3 digit, 0.56’,Red
- Maximum Display: 500
- Over Range: Display ”H”
- Dimension: 70*41mm
- Mounting Size : 68*38mm
