Phase Failor Relay Three Phase monitoring Relay Phase Sequence Vsp2 And 3 SINGLE PHASING PREVENTOR, For Electrical Panels

SKU: phase sequence | Brand:

৳2189 ৳3289

Quantity

Call +8801711078962 Ask about this product

Share this product:

Facebook Messenger WhatsApp

Phase Failor Relay Three Phase Monitoring Relay Phase Sequence

Product Details:

Usage/ApplicationElectrical Panels
Model Name/Number: VSP3
Mounting Size: 91 x 48 mm
Brand: Minilec
Supply Voltage: 415 VAC +- 20%, 50 Hz +- 3%
Output Relay: Contact1 No
Output Contact Rating5 Amp, 240 VAC
Unbalance Trip Setting50 V +- 10 VAC
Trip Time Delay For3.5 secs. +- 1.5 sec
Dimensions103 x 66 x 43 mm
Mounting TypePanel Mounting
Weight250gms

Product Details:

Connector Type: ‎Screw
Contact Type ‎Normally Open
Current Rating ‎5 Amps
Mounting Type ‎Panel Mount
Brand ‎MINILEC
Operation Mode ‎Automatic
Coil Voltage
415 Volts
Contact Current Rating ‎5 Amps
Maximum Switching Current ‎5 Amps
Manufacturer ‎MINILEC
Model ‎VSP3
Product Dimensions ‎6.6 x 4.8 x 10.3 cm; 200 g
Item model number ‎VSP3
Batteries Included ‎No
Batteries Required ‎No
Material ‎Plastic
Manufacturer ‎MINILEC
Item Weight ‎200 g

Usage/Application	Electrical Panels
Model Name/Number	VSP3
Mounting Size	91 x 48 mm
Brand	Minilec
Supply Voltage	415 VAC +- 20%, 50 Hz +- 3%
Output Relay Contact	1 No
Output Contact Rating	5 Amp, 240 VAC
Unbalance Trip Setting	50 V +- 10 VAC
Trip Time Delay For	3.5 secs. +- 1.5 sec
Dimensions	103 x 66 x 43 mm
Mounting Type	Panel Mounting
Weight	250gms

Features:

Single phasing, reverse phasing, unbalanced supply

Auto reset, 1 NO output contact Suitable for any HP/kW rating monoblock pumps Pre-wired terminals for easy connections
